DESCRIPTION
- Weight indicator in DIN box suitable for front panel mounting.
- Dimensions: 96x130x96 mm (drilling template: 92×92 mm).
- 6-digit semi-alphanumeric red LED display (14 mm height).
- 8 signalling LED.
- 5-key keyboard.
- IP54 front panel protection rating (IP65 front optional).
- Real-time clock/calendar with buffer battery.
- Extractable screw terminal blocks.
LAUMAS W200 Series
MAIN FUNCTIONS
- Connections to:
– PLC via analog output (on request);
– PC/PLC via RS485/RS232 (up to 99 instruments with line repeaters, up to 32 without line repeaters);
– remote display and printer via RS485/RS232;
– up to 8 load cells in parallel by junction box;
– intelligent junction box or other multichannel instruments: allow the use of advanced functions as digital equalization, load distribution analysis and automatic diagnostics. - Digital filter to reduce the effects of weight oscillation.
- Theoretical calibration (via keyboard) and real calibration (with sample weights and the possibility of weight linearization up to 8 points).
- Tare weight zero setting.
- Automatic zero setting at power-on.
- Gross weight zero tracking.
- Semi-automatic tare (net/gross weight) and preset tare.
- Semi-automatic zero.
- Displaying of the maximum weight value reached (peak).
- Direct connection between RS485 and RS232 without converter.
- Weight value printing with date and time via keyboard or external contact.
- TCP/IP WEB APP
Integrated software in combination with the Ethernet TCP/IP option for remote supervision, management and control of the instrument.
